Plustek SmartOffice SN8016U A3 Document Scanner

This is a departmental-class A3 document scanner built for high-volume batch scanning. It features a 100-sheet ADF, dual CIS sensors for simultaneous duplex scanning, and dual connectivity (USB and Ethernet). The trade-off is that it's a specialized piece of office equipment—large, heavy, and strictly for documents—but if you need to digitize stacks of paper quickly and reliably, it's a serious workhorse.

Scan Performance

• Up to 80 ppm / 160 ipm (Grayscale / B&W, 300 dpi, A4 landscape)

• Up to 55 ppm / 110 ipm (Color, 200 dpi, A4 landscape)

• Up to 36 ppm / 72 ipm (Color, 300 dpi, A4 landscape)

• Daily duty cycle: Up to 8,000 pages

• Optical resolution: 600 dpi

• Hardware resolution: 600 × 600 dpi

Paper Handling

• Maximum paper size: A3 (up to 297 × 5080 mm)

• Minimum paper size: 13.2 × 13.2 mm

• ADF capacity: 100 sheets (A4/Letter), 50 sheets (A3), 20 sheets (business cards)

• Supports paper weights from 40 to 220 g/m²

• Ultrasonic double-feed detection to prevent jams

• Handles mixed batches without sorting

Connectivity

• USB 2.0

• RJ45 Ethernet (Network)

• TWAIN compliant driver

Scanner Specifications

• Scanner Type: Sheetfed (ADF)

• Image Sensor: CIS × 2 (duplex scanning)

• Light Source: LED

• Color Depth: Color 48-bit in / 24-bit out; Grayscale 16-bit in / 8-bit out; B&W 1-bit

• Control Panel: 4 main buttons (Up, Down, Scan, Standby) + 9 customizable function keys

Software & Compatibility

• Bundled Software: Plustek DocAction, Plustek DocTWAIN, Plustek OCR (ABBYY FineReader)

• Supported OS: Windows XP / Vista / 7 / 8 / 10 / 11, Linux (for system integration)

• System Requirements: CPU ≥ 3.2GHz, RAM ≥ 4GB, HDD ≥ 6GB, Display ≥ 1024×768

Design & Power

• Dimensions: 436 × 262 × 266 mm

• Weight: 6.57 kg

• Power: 24 VDC / 1.25 A

• Component Life: Separation pad (100,000 scans), Pick roller (300,000 scans)

In the Box

• Scanner, power adapter, software CD, setup guide, warranty card
